High-performance cast polyurethane elastomer systems for industrial wheels and load-bearing rollers — forklift & pallet-truck wheels, caster wheels, AGV wheels, guide wheels and conveyor/drive rollers. Engineered for high abrasion resistance, high load capacity and excellent resilience under continuous load cycling. We supply both hot-cast TDI (MOCA / HQEE) and cold-cast MDI systems, with hardness and rebound tuned to your duty.
30 MPa
Sustained load capacity
30–50
Abrasion loss mm³ (hot-cast)
A60–D75
Hardness Shore
1M+
Load cycles <5% strength loss
−40~120
Operating temp °C
Key Features
Excellent abrasion resistance DIN 53516 abrasion loss as low as 30 mm³ (hot-cast TDI) for long wheel life.
High load capacity Heavy industrial wheels and high-pressure rollers up to 30 MPa sustained compressive load.
Adjustable hardness From soft (Shore A 60) to ultra-hard roller systems (Shore D 75) in one product family.
Strong dynamic performance Stable rebound and deformation resistance — tested through 1 million cycles with < 5% strength loss.
Hydrolysis & chemical resistance Polyether variants retain ≥ 90% strength after 1,000 h at 50 °C / 95% RH.
Hot-cast & cold-cast systems TDI (MOCA/HQEE) for top mechanicals; MDI for easier, lower-toxicity casting. Customizable.
Also used for: AGV & logistics wheels, conveyor & drive rollers, coated bearings and heavy-duty load rollers. For coating & printing roller covers, see our Coating & Printing Rollers grade.
Technical Specifications
Property
Range
Test Method
Hardness
Shore A 60 – Shore D 75
ASTM D2240
Tensile strength
20–55 MPa
ASTM D412
Elongation at break
250–650%
ASTM D412
Abrasion resistance
30–80 mm³ (hot-cast from 30)
DIN 53516
Rebound resilience
35–55%
ASTM D2632
Tear strength
60–120 kN/m
ASTM D624
Sustained load
up to 30 MPa
—
Operating temperature
−40 °C to +120 °C
ISO 9142
Parameters customizable by formulation design and application; typical values for reference, not a binding specification.
Hot-Cast vs Cold-Cast Systems
Hot-Cast TDI (MOCA / HQEE) Top mechanical properties — highest abrasion resistance, load capacity and dynamic performance for heavy-duty wheels.
Cold-Cast MDI Prepolymer Easier, lower-toxicity processing for general wheels & rollers; optimized viscosity (1,500–3,500 cps at 80 °C) for smooth casting and demoulding.
Casting Processes
Centrifugal Casting Uniform-density covers for wheels and cylindrical rollers.
Open-Mold Casting For large wheels and simple-geometry parts.
Vacuum Casting Void-free covers for precision and high-load wheels.
Automated Casting Compatible with PU casting machines and automated metering.
Packaging, Storage & Handling
Packaging Prepolymer and curative supplied in iron drums; palletised for export. Bulk on request.
Storage Store sealed in a cool, dry, ventilated area away from moisture. Shelf-life details on request.
Handling & Safety Avoid eye/skin contact; wear safety glasses. Wash skin with soap and water; flush eyes with water and seek medical attention. Full MSDS on request.
One-Stop PU Elastomer Solution
Beyond raw materials, BlendPolyol provides matched equipment and tooling — a complete production-line partner, not just a chemical supplier:
10+ years in PU raw materials Specialised PU elastomer & polyol manufacturer serving industry worldwide.
Custom formulation Hardness, rebound and abrasion tuned to your wheels and rollers.
Equipment integration Casting machines, mixing systems and moulds as a complete solution.
Global export & fast reply Export to EU, Latin America, Asia and beyond — we respond within 24 hours.
From Sample to Bulk Order
1. Share your duty Tell us load, speed, hardness target and environment — we recommend hot- or cold-cast.
2. Sample & validate Trial-cast wheels; we fine-tune hardness, rebound and abrasion for your line.
3. Scale to bulk Confirm the formula and order in bulk with flexible MOQ and tiered lead times.
Frequently Asked Questions
Hot-cast (TDI) or cold-cast (MDI) for wheels?Hot-cast TDI with MOCA/HQEE gives the best abrasion resistance and load capacity for heavy-duty wheels; cold-cast MDI is easier, lower-toxicity casting for general wheels and rollers. We recommend based on load and volume.
What hardness for forklift/AGV wheels?Typically Shore A 85–95 for high-load forklift and AGV wheels; softer grades for quiet, floor-friendly casters. Tuned via prepolymer NCO and chain-extender ratio.
How is the wheel bonded to the metal/plastic core?The PU is cast directly onto a primed core for a strong chemical + mechanical bond; we advise on core preparation and primer.
Can the formulation be customized?Yes. Hardness, rebound, abrasion and processing are all customizable. OEM/ODM supported — request a TDS, MSDS and sample; we reply within 24 hours.
Need PU elastomer for wheels & rollers?
Get a tailored formulation, full TDS & MSDS, and a sample for casting validation.
✓ Hot-cast & cold-cast✓ TDS · MSDS · COA✓ Reply within 24 h
